This is a fully automatic cable cutting and stripping machine. It can complete wire cutting, wire stripping at both ends, and wire stripping in the middle.

Model: HL-MAX2-ST50
Brand: Hilong

Model：HL-MAX2-ST50

Features：

○ touch screen LCD display

○ Function: wire cutting, both ends stripping, middle stripping

Specifications：

Machine dimension: 650*570*425mm

Weight：108KG Power：800W

Electrical connection: 110V/220V 50HZ/60HZ

Operation interface: 7 inch Chinese and English switching touch screen display

Wire cross section: MAX￠14mm (Round sheath wire)

Wire cross section: 1.0~50mm² (BV wire maximum 35mm², BVR wire maximum 50mm²)

Length accuracy： ± 0.2mm

Max conduit inside diameter:￠17mm (Motor driven jump tube, no need to connect air pump)

Wire length range：Max 100m

Round sheath outer wire strip length: Front end:1-200mm, rear end:1-150mm

50mm² wire strip length：Front end:1-100mm; rear end:1-100mm

Blade material: high-speed steel

Transport speed: (L=200mm） 3000~4000pieces /hour

Drive method for inlet and outlet weir wheels: screw motor lifts the wheels, and the inlet and outlet wire pressure wheels are automatically adjusted up and down

Driving mode: 8-wheel belt drive (silent hybrid stepper motor, 0.1mm forward per step)
