Iron plate silent terminal machine 2T

Features：

1.With the inverter-driven,it makes the machine without the mechanized operation delay and failure

from the traditional clutch,and simplify internal mechanical parts,reduce the wearing or replacement.

Large torque,small vibration,high stability,quiet working.Ensure the right amount of force when　crimping the terminals to wires.

2.Can work with a variety of straight,horizontal molds,various terminals can be crimped in one　machine by changing the molds.

3.There is the upward and downward punch on the panel,do not need to shake the spindle with　a wrench when debugging the mold.

4.You can adjust the machine working range 1-20times,the working interval time range 0-20min.

Specifications：

220V 50HZ/60HZ

Motor power 750W

Pressure 20KN

Stroke 30mm

Weight 48KG

Dimensions 220*240*640

(40 stroke can be customized)
